About TSURUMIYonago Plant
Production Bases
Yonago Plant
Total Site Area: 29,232m2 /
Total Floor Area: 12,742m2
2700, Yomi-cho, Yonago, Tottori 683-0851, Japan
Phone: +81-859-29-0811, Fax: +81-859-24-0602
Certification: ISO 9001
-
Manufacturing primarily large drainage pumps,large submersible pumps, and liquid ring vacuum pumps and compressors
Tsurumi’s Yonago Plant is responsible for manufacturing primarily large drainage pumps, large submersible pumps, liquid ring vacuum pumps, and liquid ring compressors.
It features an 11-meter-deep Underground Test Tank with a capacity of 3,500 m3 and a 10-meter-deep Test Tank with a capacity of 3,100 m3.
The plant produces drainage pumps with a 2,000 mm discharge diameter, non-primed advance standby pumps, and liquid ring vacuum pumps and compressors with diameters exceeding 600 mm.
In addition, the facility’s Fluid Research Building conducts measurement and analysis using experimental equipment and material testing and analysis equipment, and its Modeling Research Building carries out an extensive program of experimentation and research into sand molding as part of day-to-day research dedicated to enabling Tsurumi to supply better products to its customers.
Aiming to Enhance Manufacturing Capabilities
Production Facilities
Production Building No. 1
Assembly Area, Large Pump Test Site, Receiving Inspection
-
Production Building No. 1
-
Measurement Room
-
Measurement of parts with a wide-view 3-D measuring instrument
Underground Test Tank
Performance Testing Facility
Underground Test Tank
Production Building No. 2
NC Machining, Painting & Coating Facilities
-
Production Building No. 2
-
Numerical Control Shaft Lathe
-
Horizontal Boring Milling Machine
-
Turning Center
-
Five-Face Grinding Machine
Production Building No. 3
Testing Facility, Receiving Inspection, General Purpose Machinery
-
Production Building No. 3
-
Test Tank
-
Large Submersible Pump Testing Facility
-
Testing Facility
Fluid Research Building
Development & Testing Facilities
-
Fluid Research Building
-
Test Equipment
Office Building
-
Office Building
-
Training Room
Enabling New Manufacturing Methods
Modeling Research Building
Achieving shorter delivery times by using Japanese-made sand mold 3D printers and in-house casting.
Relevant information such as results and suggestions for improvements are fed back in real time.
-
Artificial Sand 3D Printer
-
Natural Silica Sand 3D Printer
-
Modeled Objects
(Processed Finished Products / Mold Samples)
